| Type: | Drill Pipe | Machine Type: | Drilling Tool |
| Applicable Industries: | Construction works,Energy & Mining | Material: | Chromium, 555iMnMo |
| Weight (KG): | 5 | Processing Type: | Forging |
| Video Inspection: | Provided | Use: | Energy & Mining |
| Machinery Test Report: | Provided | Product Name: | Pneumatic Drill Rod |
| Marketing Type: | New Product 2020 | Size (mm): | 500-6000 |
| Head Diameter (mm): | 26/28/30/32/34/36/38 | Steel Grade: | Ovako 495 |
| Hex Shank | Hex Shank | Hex Shank | Hex Shank |
Introduction
Product Introduction:
Plug-hole Integral Drill Steel is widely used in stone pit field to drill small holes. Because of the integration of the drilling rods and drilling bits, it can be matched directly with rock drills without shank adapter or coupling sleeve, these advantages avoid the wastage of energy, and improve the drilling efficiency remarkably.
H19-Plug Hole Integral Drill Steel- Shank 19 x108mm
Plug-hole drill steels are used for splitting and squaring stone blocks.
| H19 | |||||
| Integral Drill Steels | Length | Bit Dia. | Weight | Parts No. | |
| mm | Foot | mm | (kg) | ||
Shank 19mm×108mm
|
400 | 1'4'' | 29 | 1.3 | I19-108-0400-29 |
| 500 | 1'8'' | 29 | 1.5 | I19-108-0500-29 | |
| 800 | 2'7'' | 28 | 2.2 | I19-108-0800-28 | |
| 1000 | 3'33/8'' | 28 | 2.6 | I19-108-1000-28 | |
| 1200 | 3'11'' | 27 | 3 | I19-108-1200-27 | |
| 1600 | 5'3'' | 27 | 3.9 | I19-108-1600-27 | |
| 2400 | 7'10'' | 26 | 5.7 | I19-108-2400-26 | |
| 3200 | 10'6'' | 25 | 7.5 | I19-108-3200-25 | |
| 4000 | 13'1'' | 24 | 9.2 | I19-108-4000-24 | |
| 400 | 1'4'' | 24 | 1.3 | I19-108-0400-24 | |
| 800 | 2'7'' | 23 | 2.2 | I19-108-0800-23 | |
| 600 | 2' | 27 | 1.7 | I19-108-0600-27 | |
| 1200 | 3'11'' | 26 | 3 | I19-108-1200-26 | |
| 2000 | 6'7'' | 24 | 4.8 | I19-108-2000-24 | |
| 2400 | 7'10'' | 24 | 5.7 | I19-108-2400-24 | |
| 2700 | 8'10'' | 24 | 6.3 | I19-108-2700-24 | |
| 400 | 1'4'' | 35 | 1.3 | I19-108-0400-35 | |
| 800 | 2'7'' | 34 | 2.2 | I19-108-0800-34 | |
Shank 22mm×108mm |
400 | 1'4'' | 24 | 1.5 | I22-108-0400-24 |
| 400 | 1'4'' | 29 | 1.5 | I22-108-0400-29 | |
| 600 | 2' | 27 | 1.7 | I22-108-0600-27 | |
| 800 | 2'7'' | 23 | 2.3 | I22-108-0800-23 | |
| 800 | 2'7'' | 28 | 2.3 | I22-108-0800-28 | |
| 1200 | 3'11'' | 23 | 3.2 | I22-108-1200-23 | |
| 1600 | 5'3'' | 27 | 4 | I22-108-1600-27 | |
| 2000 | 6'7'' | 28 | 5 | I22-108-2000-28 | |
| 2400 | 7'10'' | 26 | 5.8 | I22-108-2400-26 | |
| 3200 | 10'6'' | 25 | 7.5 | I22-108-3200-25 | |
| Plug hole Integral Steels | Length | Bit | Turned | Weight | Parts No. |
| Dia. | Length | ||||
Shank 19mm×108mm |
210 | 17 | 150 | 0.7 | I19-108-0210-17 |
| 210 | 20 | 150 | 0.7 | I19-108-0210-20 | |
| 210 | 22 | 150 | 0.7 | I19-108-0210-22 | |
| 260 | 20 | 200 | 0.8 | I19-108-0260-20 | |
| 260 | 22 | 200 | 0.8 | I19-108-0260-22 | |
| 310 | 22 | 250 | 0.9 | I19-108-0310-22 | |
| 340 | 20 | 280 | 1 | I19-108-0340-20 | |
Packing & Delivery
| Minimum Order Quantity | N/A |
| Price | |
| Packaging Details | Standard Export Delivery Package |
| Delivery Time | 7days |
| Payment Terms | T/T |
| Supply Ability | Based on Detailed Order |
