9 1/2 Inch 244.5mm Pdc Bit Of 5 Wing Steel Body

9 1/2 Inch 244.5mm Pdc Bit Of 5 Wing Steel Body Featured Image
  • 9 1/2 Inch 244.5mm Pdc Bit Of 5 Wing Steel Body
  • 9 1/2 Inch 244.5mm Pdc Bit Of 5 Wing Steel Body
  • 9 1/2 Inch 244.5mm Pdc Bit Of 5 Wing Steel Body

Short Description:

Size of Rock Bit 9 1/2 INCH
241.3 MM
 IADC Code S323
Thread Connection 6 5/8 API REG PIN
WOB (Weight On Bit) 25~120 KN
RPM 60~350
Formation Suitable for soft to medium hard formation
Net Weight 78KG
WG kg 82kg
Flow Rate L/S 25~38

  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month

    • Product Detail

    Product Tags

    Product Detail

    Introduction of PDC drill bit

    PDC TRICONE BITS

    ♦ Steel body with hardening tungsten carbide surface(WC),make the drill bit both high strength and very strong abrasion
    resistance.
    ♦ Dedicated PDC cutter can improve the life and shield the risk of complex formation drill not passed.
    ♦ Raw materials: Alloy steel with a special treatment, achieve better mechanical properties (Rp0, 2: 1200MPa; Rm: 1100 MPa)
    ♦ Low torque spiral design and software designed tooth reduce the cutting edge wear & increase life
    ♦ (no repair life up to 8300 M/pc).
    ♦ The unique parabolic crown-shaped design and tooth balance design keeps smooth drilling under high speed.
    ♦ (Speeds up to 30~40m/h.)
    ♦ The scientific drilling dynamic equilibrium design and hydraulic balance design make the drilling process more smooth.
    ♦ Authoritative API standard and ISO certification, quality and service will be better ensured.
    Bit Type
    6”
    8-1/2”
    8-1/2”
    12-1/4”
    Bit Type
    17-1/2” GM1606T
    IADC Code
    M423
    M432
    M323
    M432 M332
    IADC Code
    M323
    M332
    Blade
    5
    6
    8
    6
    Blade
    6
    Cutter Size (mm)
    Φ13MM
    Φ16MM
    Φ13MM
    Φ16MM
    Cutter Size (mm)
    Φ16MM；Φ13MM
    Nozzle Qty/Type
    5
    13.2
    9.6
    30.78
    Cutter Qty
    Φ16×58；Φ13×81
    Nozzle Qty/Type
    3NZ
    6NZ
    4NZ
    6NZ
    Nozzle Qty/Type
    8NZ
    Gauge Length
    1.5”
    2.2”
    2”
    2.5”
    Gauge Length (mm)
    110
    Connection
    3-1/2” API REG
    4-1/2” API REG
    4-1/2” API REG
    6-5/8” API REG
    Connection
    7-5/8” API REG
    Make up Torque(KN.m)
    10.4~11.4
    24.1~26.5
    24.1~26.5
    51.7~56.9
    N.W./ G.W.(KG)
    338/388
    Rotary Speed(rpm）
    60-260
    60-260
    60-260
    60-260
    Nozzle Size (inch)
    10/32
    Weight on Bit(KN)
    8-50
    20-100
    20-100
    30-140
    Rotary Speed(Rpm)
    60-260
    Max.WOB(KN)
    90
    130
    130
    180
    Weight On Bit(KN)
    30-200
    Flow Rate（lps)
    10-30
    22-35
    22-35
    38-70
    Max.WOB (KN)
    240
    Flow Rate（lps)
    45-80
    Above are regular sizes for your reference. Size can be customized as per your requirement.

    PDC-BITS-FOR-152MM

    Commercial Terms of Product

    Minimum Order Quantity N/A
    Price
    Packaging Details Standard Export Delivery Package
    Delivery Time 7days
    Payment Terms T/T
    Supply Ability Based on Detailed Order
