| Condition | New | Material | Carbon steel |
| Applicable Industries | Construction works , Energy & Mining | Processing Type | Forging |
| Video outgoing-inspection | Provided | Use | Ore Mining |
| Machinery Test Report | Provided | Product name | R25 - Hex25 - R25 drifter drill rod |
| Marketing Type | Hot Product 2022 | Application | tunneling, mining |
| Brand Name | JCDRILL | Usage | top hammer drilling |
| Type | drill rod | Name | tunneling drill rod |
| Machine Type | Drilling Equipment | Word | mining drill rod |
Introduction
JCDRILL provides top hammer equipment for every application, such as underground mining and tunneling, surface mining and quarries, road and construction. Our quality can compare with world's famous brand. Look no further, we have the best top hammer
drilling tools for you
Extension rod, other names are Extension drill steel, Extension drill rod, and Extension steel, M/F rod ( Speed rod ) , Produce Hexagonal and round cross sections, Hexagon rods are more rigid, heavier and transfer energy more efficiently, while increasing flushing. Round rods are generally lighter than hexagonal rods and are normally used in extension drilling applications.
| T45 | ||||||||
| Drill Bit | Bit Dia. | NO x Button x Dia. | Flushing Hole | Weight | ||||
| mm | inch | Front | Gauge | Angle | Front | Side | （KG） | |
 |
spherical Buttons | |||||||
| 70 | 2 3/4 | 4x11 | 8x11 | 40° | 2 | 2.3 | ||
| 70 | 2 3/4 | 3x11,1x9 | 6x11 | 35° | 3 | 2.2 | ||
| 70 | 2 3/4 | 4x10,1x10 | 8x11 | 35° | 4 | 2.2 | ||
| 76 | 3 | 4x11 | 8x11 | 40° | 2 | 2.6 | ||
| 76 | 3 | 5x11 | 8x12 | 35° | 2 | 1 | 2.6 | |
| 76 | 3 | 3x11,1x11 | 6x12 | 35° | 3 | 2.4 | ||
| 76 | 3 | 4x11,1x11 | 8x12 | 35° | 4 | 2 | ||
| 89 | 3 1/2 | 4x13 | 8x13 | 40° | 2 | 4.6 | ||
| 89 | 3 1/2 | 6x11 | 8x12 | 35° | 2 | 4.6 | ||
| 89 | 3 1/2 | 3x11,2x11 | 6x13 | 35° | 3 | 1 | 4.1 | |
| 89 | 3 1/2 | 4x11,1x11 | 8x12 | 35° | 4 | 4.6 | ||
| 89 | 3 1/2 | 4x13,1x13 | 8x13 | 35° | 4 | 4.6 | ||
| 102 | 4 | 5x14 | 8x14 | 40° | 2 | 5.0 | ||
| 102 | 4 | 6x13 | 8x16 | 40° | 2 | 1 | 5.0 | |
| 102 | 4 | 3x13,2x13 | 6x14 | 35° | 3 | 1 | 4.5 | |
| 102 | 4 | 4x13,1x13 | 8x14 | 35° | 4 | 4.5 | ||
| 102 | 4 | 4x13,1x13 | 8x13 | 35° | 4 | 1 | 4.5 | |
| Parabolic Buttons | ||||||||
| 70 | 2 3/4 | 3x11,1x9 | 6x11 | 35° | 3 | 2.2 | ||
| 70 | 2 3/4 | 4x10,1x10 | 8x11 | 35° | 4 | 2.2 | ||
| 76 | 3 | 4X11 | 8x11 | 40° | 2 | 2.6 | ||
| 76 | 3 | 5X11 | 8x12 | 35° | 2 | 1 | 2.6 | |
| 76 | 3 | 3x11,1x11 | 6x13 | 35° | 3 | 1 | 2.4 | |
| 76 | 3 | 4x11,1x11 | 8x11 | 35° | 4 | 2.6 | ||
| 76 | 3 | 4x11,1x11 | 8x12 | 35° | 4 | 2.6 | ||
| 89 | 3 1/2 | 4x13 | 8x13 | 40° | 2 | 4.6 | ||
| 89 | 3 1/2 | 6x11 | 8x12 | 35° | 2 | 4.6 | ||
| 89 | 3 1/2 | 3x11,2x11 | 6x13 | 35° | 3 | 1 | 4.1 | |
| 89 | 3 1/2 | 4x11,1x11 | 8x12 | 35° | 4 | 4.6 | ||
| 89 | 3 1/2 | 4x13,1x13 | 8x13 | 35° | 4 | 4.6 | ||
| Drill Roll | Length | Dimaeter | Weight | |||||
| mm | inch | mm | inch | （KG） | ||||
 |
1830 | 6' | 46 | 1 3/4 | 21.6 | |||
| 2435 | 8' | 46 | 1 3/4 | 28.3 | ||||
| 3050 | 10' | 46 | 1 3/4 | 35.2 | ||||
| 3660 | 12' | 46 | 1 3/4 | 42.1 | ||||
| 4270 | 14' | 46 | 1 3/4 | 48.9 | ||||
| 5530 | 18' | 46 | 1 3/4 | 63 | ||||
| 6095 | 20' | 46 | 1 3/4 | 69.3 | ||||
 |
1525 | 5' | 46 | 1 3/4 | 21.2 | |||
| 1830 | 6' | 46 | 1 3/4 | 24.6 | ||||
| 3050 | 10' | 46 | 1 3/4 | 38.2 | ||||
| 3660 | 12' | 46 | 1 3/4 | 45 | ||||
| 4270 | 14' | 46 | 1 3/4 | 51.9 | ||||
| 5530 | 18' | 46 | 1 3/4 | 66 | ||||
| 6095 | 20' | 46 | 1 3/4 | 72.3 | ||||
 |
3050 | 10' | 52 | 2 | 46.6 | |||
| 3660 | 12' | 52 | 2 | 55.8 | ||||
| 4270 | 14' | 52 | 2 | 63.8 | ||||
| 5530 | 18' | 52 | 2 | 81.5 | ||||
| 6095 | 20' | 52 | 2 | 89.4 | ||||
| Coupling | Length | Dimaeter | Weight | |||||
| mm | inch | mm | inch | （KG） | ||||
 |
210 | 8 1/4 | 63 | 2 1/2 | 3 | |||
| 210 | 8 1/4 | 66 | 2 4/7 | 3.3 | ||||
| Minimum Order Quantity | N/A |
| Price | |
| Packaging Details | Standard Export Delivery Package |
| Delivery Time | 7days |
| Payment Terms | T/T |
| Supply Ability | Based on Detailed Order |
