| Condition | New | Material | Carbon steel |
| Applicable Industries | Construction works , Energy & Mining | Processing Type | Forging |
| Video outgoing-inspection | Provided | Use | Ore Mining |
| Machinery Test Report | Provided | Product name | R25 - Hex25 - R25 drifter drill rod |
| Marketing Type | Hot Product 2022 | Application | tunneling, mining |
| Brand Name | JCDRILL | Usage | top hammer drilling |
| Type | drill rod | Name | tunneling drill rod |
| Machine Type | Drilling Equipment | Word | mining drill rod |
Introduction
Product Application
Drill pipes are widely used in mining,geological exploring and all kinds of drilling(water,oil,gas,etc) projects.As a leading drill pipe manufacture,we make all kinds of standards and non-standard drill pipes for our customers. Our drill pipes including steel drill pipe,mining drill pipe,water well drill pipe,oil well drill pipe,API drill pipe,DTH drill rod,wireline drill rod,etc. We can produce as your request of carbide size, different length of drill rods.
| T45 | ||||||||
| Drill Bit | Bit Dia. | NO x Button x Dia. | Flushing Hole | Weight | ||||
| mm | inch | Front | Gauge | Angle | Front | Side | （KG） | |
 |
spherical Buttons | |||||||
| 70 | 2 3/4 | 4x11 | 8x11 | 40° | 2 | 2.3 | ||
| 70 | 2 3/4 | 3x11,1x9 | 6x11 | 35° | 3 | 2.2 | ||
| 70 | 2 3/4 | 4x10,1x10 | 8x11 | 35° | 4 | 2.2 | ||
| 76 | 3 | 4x11 | 8x11 | 40° | 2 | 2.6 | ||
| 76 | 3 | 5x11 | 8x12 | 35° | 2 | 1 | 2.6 | |
| 76 | 3 | 3x11,1x11 | 6x12 | 35° | 3 | 2.4 | ||
| 76 | 3 | 4x11,1x11 | 8x12 | 35° | 4 | 2 | ||
| 89 | 3 1/2 | 4x13 | 8x13 | 40° | 2 | 4.6 | ||
| 89 | 3 1/2 | 6x11 | 8x12 | 35° | 2 | 4.6 | ||
| 89 | 3 1/2 | 3x11,2x11 | 6x13 | 35° | 3 | 1 | 4.1 | |
| 89 | 3 1/2 | 4x11,1x11 | 8x12 | 35° | 4 | 4.6 | ||
| 89 | 3 1/2 | 4x13,1x13 | 8x13 | 35° | 4 | 4.6 | ||
| 102 | 4 | 5x14 | 8x14 | 40° | 2 | 5.0 | ||
| 102 | 4 | 6x13 | 8x16 | 40° | 2 | 1 | 5.0 | |
| 102 | 4 | 3x13,2x13 | 6x14 | 35° | 3 | 1 | 4.5 | |
| 102 | 4 | 4x13,1x13 | 8x14 | 35° | 4 | 4.5 | ||
| 102 | 4 | 4x13,1x13 | 8x13 | 35° | 4 | 1 | 4.5 | |
| Parabolic Buttons | ||||||||
| 70 | 2 3/4 | 3x11,1x9 | 6x11 | 35° | 3 | 2.2 | ||
| 70 | 2 3/4 | 4x10,1x10 | 8x11 | 35° | 4 | 2.2 | ||
| 76 | 3 | 4X11 | 8x11 | 40° | 2 | 2.6 | ||
| 76 | 3 | 5X11 | 8x12 | 35° | 2 | 1 | 2.6 | |
| 76 | 3 | 3x11,1x11 | 6x13 | 35° | 3 | 1 | 2.4 | |
| 76 | 3 | 4x11,1x11 | 8x11 | 35° | 4 | 2.6 | ||
| 76 | 3 | 4x11,1x11 | 8x12 | 35° | 4 | 2.6 | ||
| 89 | 3 1/2 | 4x13 | 8x13 | 40° | 2 | 4.6 | ||
| 89 | 3 1/2 | 6x11 | 8x12 | 35° | 2 | 4.6 | ||
| 89 | 3 1/2 | 3x11,2x11 | 6x13 | 35° | 3 | 1 | 4.1 | |
| 89 | 3 1/2 | 4x11,1x11 | 8x12 | 35° | 4 | 4.6 | ||
| 89 | 3 1/2 | 4x13,1x13 | 8x13 | 35° | 4 | 4.6 | ||
| Drill Roll | Length | Dimaeter | Weight | |||||
| mm | inch | mm | inch | （KG） | ||||
 |
1830 | 6' | 46 | 1 3/4 | 21.6 | |||
| 2435 | 8' | 46 | 1 3/4 | 28.3 | ||||
| 3050 | 10' | 46 | 1 3/4 | 35.2 | ||||
| 3660 | 12' | 46 | 1 3/4 | 42.1 | ||||
| 4270 | 14' | 46 | 1 3/4 | 48.9 | ||||
| 5530 | 18' | 46 | 1 3/4 | 63 | ||||
| 6095 | 20' | 46 | 1 3/4 | 69.3 | ||||
 |
1525 | 5' | 46 | 1 3/4 | 21.2 | |||
| 1830 | 6' | 46 | 1 3/4 | 24.6 | ||||
| 3050 | 10' | 46 | 1 3/4 | 38.2 | ||||
| 3660 | 12' | 46 | 1 3/4 | 45 | ||||
| 4270 | 14' | 46 | 1 3/4 | 51.9 | ||||
| 5530 | 18' | 46 | 1 3/4 | 66 | ||||
| 6095 | 20' | 46 | 1 3/4 | 72.3 | ||||
 |
3050 | 10' | 52 | 2 | 46.6 | |||
| 3660 | 12' | 52 | 2 | 55.8 | ||||
| 4270 | 14' | 52 | 2 | 63.8 | ||||
| 5530 | 18' | 52 | 2 | 81.5 | ||||
| 6095 | 20' | 52 | 2 | 89.4 | ||||
| Coupling | Length | Dimaeter | Weight | |||||
| mm | inch | mm | inch | （KG） | ||||
 |
210 | 8 1/4 | 63 | 2 1/2 | 3 | |||
| 210 | 8 1/4 | 66 | 2 4/7 | 3.3 | ||||
| Minimum Order Quantity | N/A |
| Price | |
| Packaging Details | Standard Export Delivery Package |
| Delivery Time | 7days |
| Payment Terms | T/T |
| Supply Ability | Based on Detailed Order |
